- Description
-
Details
Features and Advantages
● One button to switch X-ray source
● Excellent testing performance and flexible settings
● Multiple scanning modes: spiral, offset, limited angle and others
● Excellent expandability
Resolution
* Spatial resolution measured with resolution chartDetectability
200 nmSpatial resolution*
500 nm
X-ray source
Tube type Open, Reflection
Open, Transmission (micro / nano focus)Voltage
300kV, 240kV, 225kV, 190kV, 160kV240kV, 225kV, 190kV, 160kV
Detector1 (Flat panel)
Imaging area427 × 427 mm
Pixel matrix3072 × 3072 pixel
Sample
Maximum size600 x 600 mm（Diameter x Height）
Maximum weight25 kg
Equipment
Dimension
2770 x 1540 x 2040 mm（Length x Width x Height)Weight
8000 kg - Reviews
-
