- Description
-
Details
Features and Advantages
● High resolution and high penetrating ability
● Sample stage with large load-bearing
● Multiple scanning modes: spiral, offset, limited angle and others
● Excellent expandability
Resolution
* Spatial resolution measured with resolution chartDetectability
500 nmSpatial resolution*
2 μm
X-ray source
Tube typeOpen, Reflection
Voltage300kV, 240kV, 225kV, 190kV, 160kV
Detector1 (Flat panel)
Imaging area427 × 427 mm
Pixel matrix3072 × 3072 pixel
Sample
Maximum size600 x 550 mm（Diameter x Height）
Maximum weight25 kg
Equipment
Dimension
2770 x 1440 x 2040 mm（Length x Width x Height)Weight
7500 kg - Reviews
-
