FEATURES:
SPECIFICATION:
1. Wi-Fi connection
Benefit1: Easily carry the unit anywhere
Benefit2: Free you from the hassle of connecting/disconnecting cables.
Benefit3: Ideal for on-machine measurements.
Benefit4: Can be shared with multiple tablets.
2. All-In-One solution
Amplifier is integrated into Drive unit.
Achieved complete portability.
Everything is combined into the one unit.
3. Upper Class Compatible
Because of Windows operation, analysis capabilities equivalent to higher models are guaranteed.
No CPU limitations enhance to a wide variety of analysis parameters and standards.
4. High Density Battery
Achieve 2000 measurements on a single full charge.
Features wireless all-day operation without a power source.
5. High Straightness Accuracy
Guarantee 0.5μm/25mm.
Precision even a small.
6. Multi-Play-Function
Measuring instructions can be sent from multiple PCs.
Measurements can be carried out while having lively discussions.
7. Profiler Version
Straightness accuracy complements reliability of primary profile.
Combination use with Pro-Key is more convenience.
8. Waviness Version
Straightness accuracy complements waviness reliability.
Complies with special standards for the steel industry, such as EN10049.
Parameters
Roughness, Waviness, Warpage, Profile, Step Height
Measuring range800 μm
Resolution0.0016 μm
Traverse range25 mm
StraightnessLess than 0.5 μm Pick-up
Interchangeable stylus, Comply small or deep grove
Measuring force0.75 mN
Pick-up vertical range17 mm Measuring magnification
Vertical (Z): 50 ~ 500,000
Horizontal (X): 1 ~ 5,000OS
Windows11pro by Tablet, Laptop, or Desktop PC - Reviews
-
